Samsung Plug In Module AMD A6-3430M Quad Core 4GB RAM 64GB SSD Windows 7 Pro System

Ultimate ease of use

With Samsung plug-in modules, you'll find displays of ultimate ease of use. Simply plug the thin PC into the Smart Signage display, with external connection cables no longer required. Because electricity and signals are transferred directly, no additional computers are needed and the environment is kept tidy. You do not need to cram with heavy desktops or laptops, saving time and effort. In addition, there is also less chance of damage and injury.



Slim, lightweight design

The optional plug-in PC module (PIM) fits perfectly with our almost borderless Smart Signage displays. For example, your business displays are streamlined and professional. The efficient design of the PIMs limits the weight to a minimum. The environment of your business displays remains neatly cleaned, allowing your customers to focus on the message on the screen.



Specification:

connectivity

·        audio In

Mic in

·        video Out

OPS 80 pin port, DisplayPort out

·        audio out

audio out

Energy

·        Energy (power)

70 W (MAX), 27 (Typical)

MORE SPECIFICATIONS

Dimensions

·        Unit dimensions (WxHxD, mm)

W200 x D175,6 mm x H34,4

·        Package dimensions (WxHxD, mm)

W430 x D250 x H55 mm

Weight

·        Weight

1.2 kg

·        Weight incl. Packaging (kg)

1.9 kg

Operating Conditions

·        Temperature

10 ~ 40

·        humidity

10 ~ 80%

General Features

·        special

AMD A6 3430M 1.7GHz quad-core APU (Boost up to 2.4 GHz), 256 KB (L1) / 1 MB (L2) cache, 4GB (DDR3 SO-DIMM 4GB x 1) Memory, SSD 64GB, Radeon HD6500 Series GPU (Integrated on APU), Window 7 Professional OS (Embedded), Gigabit Ethernet (RJ-45), USB 2.0 Port x 2, 2 x USB 3.0 Port

Certifications

·        EMC

FCC Class A, CE, VCCI, CCC, BSMI, C-Tick, CCC

·        Safety

UL / c-UL, CSA, TUV, NEMKO, KC, CCC
