PERFORMANCE
GIGABYTE UD
series motherboards use pure digital PWM + Low RDS(on) MOSFETs design to
support the 3rd Gen AMD Ryzen⢠CPUs by offering incredible precision in
delivering power to the motherboard's most power-hungry and
energy-sensitive components as well as delivering enhanced system
performance and ultimate hardware scalability.
NVMe PCIe Gen3 x4 M.2 Connector
GIGABYTE Motherboards are focused on delivering M.2 technology to
enthusiasts who want to maximize their systemâ€s potential.
GbE LAN with Bandwidth Management
GbE LAN features a network bandwidth management application which
helps to improve network latency and maintain low ping times to deliver
better responsiveness in crowded LAN environments.
HDMI 2.1 for 4K / 60P / 21:9 / HDCP 2.3 Support
HDMI 2.1, which is backwards compatible with HDMI 2.0/ 1.4 and
offering 48 Gb/s of bandwidth – twice times more than previous
generation. This unlocks the potential for users to transfer multiple
video streams, as well as a native cinematic 21:9 ratio (which most movies
are shot in), Full HDR and HDCP 2.3 support, to offer the best visual
experience for viewers.
The Industry's Leading LAN Static-Electricity & Surge Protection
GIGABYTE motherboards use ICs with up to 3 times the ESD resistance
levels compared to traditional ICs. This helps to better protect the
motherboard and its components against potential damage caused by static
electricity. GIGABYTE motherboards also feature special anti-surge ICs
that protect your motherboard, and your PC from any surge in power
delivery that may occur, helping to ensure that your PC is equipped to
deal with any potentially irregular and inconsistent power delivery.
Smart Fan 5
With Smart Fan 5 users can ensure that their gaming PC can maintain
its performance while staying cool. Smart Fan 5 allows users to
interchange their fan headers to reflect different thermal sensors at
different locations on the motherboard. Not only that, with Smart Fan 5
more hybrid fan headers that support both PWM and Voltage mode fans have
been introduced to make the motherboard more liquid cooling friendly.
Achieve fan silence. With Fan Stop, map any fan to stop completely when
temperatures drop below a specified threshold. Which fan stops, based on
readings from which sensor, and at what temperature—all of it can be
customized to your liking.
Hybrid Fan Pin Headers
Assume complete control over your liquid cooling setup! Smart Fan 5
receives up-to-the-second information on flow-rate and water-temperature
through the Hybrid Fan Pin Headers or external thermistor sensors—giving
you absolute mastery over your PC.
• All Hybrid Fan Headers can automatically detect the type of cooling
device whether it be fan or pump with different PWM or Voltage mode.
New Smart Fan 5 Software
Choose from different modes, Quiet to Full Speed, to match your
system usage preferences.
For each fan or pump, you can use the intuitive fan curve to define
trigger thresholds and corresponding fan speeds.
High-End Audio Capacitors
GIGABYTE motherboards use high-end audio capacitors. These high
quality capacitors help deliver high resolution and high fidelity audio to
provide the most realistic sound effects for gamers.
Audio Noise Guard
GIGABYTE motherboards feature an audio noise guard that essentially
separates the boardâ€s sensitive analog audio components from potential
noise pollution at the PCB level.
Solid Pin Power Connectors
GIGABYTE motherboards feature solid plated ATX 12V 8pin power
connectors for offering stable power supply while CPU overloading.
START SULFURIZATION PROTECTION
Sulfur compounds in the air can penetrate tiny onboard resistors
creating chemical change and causing these resistors to open or short. If
either of these occurs the motherboard will fail to function. By equipping
resistors with an Anti-Sulfur Design GIGABYTE gives Ultra Durable
Motherboards a whole new meaning.
The Industry's Leading Surge Protection
GIGABYTE motherboards also feature special anti-surge IC that
protect your motherboard, helping to ensure that your PC is equipped to
deal with any potentially irregular electrical spikes.
Humidity Protection Glass Fabric PCB
There is nothing more harmful to the longevity of your PC than
moisture, and most parts of the world experience moisture in the air as
humidity at some point during the year. GIGABYTE motherboards have been
designed to make sure that humidity is never an issue, incorporating a new
Glass Fabric PCB technology that repels moisture caused by humid and damp
conditions. Glass Fabric PCB technology uses a new PCB material which
reduces the amount of space between the fiber weave, making it much more
difficult for moisture to penetrate compared to traditional motherboard
PCBs. This offers much better protection from short circuit and system
malfunction caused by humid and damp conditions.
High Temperature Protection Lower RDS(on) MOSFETs Design
GIGABYTE motherboards use Low RDS(on) MOSFETs which reduce energy
wastage through unnecessary residual heat dissipation. This all amounts to
tangible energy savings which are beneficial for both end-users and the
environment without impacting system performance.
Refreshed BIOS
The BIOS is essential for users during initial setup to allow for
the most optimal settings. With a new GUI and easier to use
functionalities, GIGABYTE has been able to reinvent the BIOS to give users
a better experience while setting up their new system.
